Low-bit KV caches on MLX: what exists and what is missing

Denis Ineshin · 2026-07-25 · Read on GitHub

A research memo from mlx-quant-fidelity: the shipped state of KV-cache quantization on Apple Silicon, what it measurably costs, and where the real gaps are

Low-bit KV caches already ship on Apple Silicon. mlx-lm provides a drop-in, calibration-free QuantizedKVCache behind three generation CLI flags. It works on standard attention paths when the cache type supports conversion. New proposals should improve this path rather than rebuild it.

The existing feature still leaves important gaps. It applies the same per-token, group-scalar affine quantization to Keys and Values. KIVI and KVQuant found that Keys and Values need different treatment, while this repository's committed reports show that mlx-lm's scheme costs little at 8-bit, degrades quality at 4-bit, and fails badly at 4-bit on at least one popular checkpoint. Performance is not automatic either. An upstream codebook-prefill proof of concept reported cosine similarity 1.0 against its dequantized reference but lost badly on wall clock. Its author eventually recommended the scalar format that mlx-lm already uses.

This memo covers mlx-lm's current implementation and measured fidelity cost, then compares it with KIVI, KVQuant, other inference stacks, and public Metal-kernel work.

The memo is documentary. At drafting time (2026-07-25), the upstream API and repository states were checked against installed mlx 0.31.2, mlx-lm 0.31.3, and the public repositories. mlx-lm source links are pinned to the v0.31.3 tag.

The fidelity numbers come from committed, public reports in this repository. Those reports record the software versions. The author identifies the hardware as an M1 Max with 32 GB of unified memory, but the report files do not capture it. Nothing was rerun for this write-up. Portable memory and quality claims remain separate from hardware-bound throughput claims.

1. What mlx-lm ships today

The shipped cache (QuantizedKVCache, mlx-lm v0.31.3) quantizes both Keys and Values with mx.quantize(x, group_size, bits), defaulting to 64-element groups at 8 bits. mx.quantize groups along the last axis. For a KV tensor, that axis is one head's head_dim. Each token's per-head Key and Value vectors are sliced into 64-element groups. Each group gets an affine scale and bias from its own minimum and maximum, so head_dim must be divisible by the group size. In the literature's terms, this is per-token group-scalar quantization. It applies the same scheme to K and V after RoPE and requires no calibration.

A full KVCache converts through to_quantized(group_size=64, bits=4). The method returns a new QuantizedKVCache containing a quantized copy of everything stored so far. Its 4-bit default differs from the constructor's 8-bit default. The generation CLI exposes the path as --kv-bits, --kv-group-size, and --quantized-kv-start (generate.py).

The quantize-start flag does not preserve a permanently full-precision prefix. In the CLI it defaults to 5,000 (the Python generate_step API defaults to 0). Generation uses a full-precision cache until the first conversion check after the cache reaches or exceeds that threshold. Token-by-token decode can hit the boundary exactly; chunked prefill can overshoot it. At that check the entire stored cache is quantized in one shot, including the prefix; everything after is quantized as it is written. The stored prefix does not remain full precision. Its computation history is still different from quantize-from-zero, because those prefix activations were produced while attention used a full-precision cache. Deferring conversion delays the memory win and preserves an exact pre-boundary history, but it does not by itself establish how post-boundary drift compares with stress mode.

MLX itself has no built-in quantized attention. The mx.fast namespace in mlx 0.31.2 contains no quantized scaled-dot-product-attention op (the state of the upstream request is covered in section 5). Instead, mlx-lm composes quantized attention in Python (quantized_scaled_dot_product_attention, models/base.py): one mx.quantized_matmul for the scores against the packed Keys, a softmax, and a second mx.quantized_matmul against the packed Values. mx.quantized_matmul reads the packed layout directly, so no full-precision copy of the cache is ever materialized. The dispatch is a duck-type check: any cache carrying a bits attribute routes to the two-matmul path, everything else to mx.fast.scaled_dot_product_attention. The composition materializes the full score matrix rather than streaming it, and it raises on attention sinks.

Four coverage limits were verified at the pinned tag:

• Sliding-window caches cannot quantize. RotatingKVCache.to_quantized raises NotImplementedError ("RotatingKVCache Quantization NYI"), and the batch variant matches.
• Some caches skip quantization silently. The CLI's conversion helper only converts caches that define to_quantized. The batch, chunked, and composite cache classes do not define it. On those paths, --kv-bits is a no-op with no warning and no memory saving.
• MLA models crash. On DeepSeek-V3-architecture models, quantized caches break at the source level: the attention code calls .swapaxes on what update_and_fetch returns (models/deepseek_v3.py), and a QuantizedKVCache returns packed tuples, producing AttributeError: 'list' object has no attribute 'swapaxes' (mlx-lm #1082, open at drafting time). The architecture family behind several flagship 2026 models has no working quantized-KV path on mlx-lm.
• Low bit-widths are mechanically reachable, with one exception. mx.quantize accepts 2, 3, 4, 5, 6, and 8 bits on mlx 0.31.2. The CLI's to_quantized conversion path works at all six widths. A directly constructed QuantizedKVCache, however, hits a packing-arithmetic shape bug at 5 or 6 bits on mlx-lm 0.31.3. The defaults and documentation steer users to 8 and 4 bits. The next two sections explain why lower widths are poor choices for this scheme.

Calibration-free 8- and 4-bit affine KV quantization ships for standard attention paths on MLX. Fidelity and architecture coverage remain open. A new design needs to improve on this implementation rather than recreate it.

2. What the shipped scheme costs

This repository's committed sample reports use paired teacher-forced scoring to evaluate the shipped cache. Each pair uses the same model and the same wikitext-2-raw/test tokens. One run uses a full-precision cache and the other uses the quantized cache. The reports compare them at each position using full-vocabulary KL divergence, top-token flip rate, and perplexity delta. The public measurement principles describe the method. The reports below are stress-mode: quantization from token 0, so every scored position sits behind a quantized cache. A committed deployment-mode sample exercises delayed conversion and scores only the post-boundary region. It covers 1,020 positions across four chunks, so it is not a matched comparison with the 100-chunk stress reports and does not establish that the two modes have equal drift. Its footer calls the first 256 positions "full-precision." That label describes their pre-boundary computation and their exclusion from the metrics. It does not describe their storage type after the boundary converts their K/V.

Each report in the table covers 51,100 positions across 100 chunks of length 512. All use 4-bit-weight community checkpoints with mlx 0.31.2 and mlx-lm 0.31.3. Each model cell links to its committed report.

8-bit is near-lossless in the mean

All three checkpoints sit at or under a 0.01-nat mean KL and low single-digit flip rates at 8 bits. The tail is not uniformly benign: Qwen2.5-7B's worst position reaches 13.1 nats even at 8-bit, and the tool's own verdicts on two of the three 8-bit runs are marginal rather than good because the flip rate clears its strictest threshold. Averages are where quantization damage hides, which is why the reports carry p99 and max.

4-bit per-token quantization is lossy where it works

Both Llamas lose real probability mass at 4 bits: the 3B model flips its top token at 11.3% of positions and gives up 0.91 perplexity points; the 1B model flips 20.5% and gives up 4.12. Whether that is acceptable depends on the workload, which is the reason the tool reports numbers instead of a blanket verdict (the thresholds behind its good/marginal/bad labels are documented in the threshold policy).

4-bit failure depends on the checkpoint, not model size

mlx-community/Qwen2.5-7B-Instruct-4bit fails at kv4: a 9.4-nat mean KL, a 99.2% flip rate, and perplexity rising from 10.8 to roughly 82,676 (a +82,665 delta). That is not degradation; the model's output distribution no longer resembles its full-cache self at almost any position. A larger model did not mean more robustness. The 7B Qwen collapses where the 1B and 3B Llamas merely degrade. A committed comparison on Qwen2.5-0.5B, also a 4-bit-weight checkpoint, shows the same family pattern at kv4 (report). That comparison also prices the group-size lever: halving the group size from 64 to 32 at 4 bits roughly halves the KL (2.56 to 1.34 nats) for 11% more cache bytes (4.5 to 5.0 bits per element), and still lands about 44× worse than 8-bit. Group size is a real but weak knob; it does not buy back the failure.

These results have three limits.

First, fidelity depends on the corpus and context length. Short-prose measurements may understate the risk for long contexts or code, so these figures are not ceilings.

Second, the measured drift includes both quantizer error and the numerics of the attention path. The quantized run uses the two-matmul composition from section 1, while the reference uses fused SDPA. That combination is the end-to-end cost paid by the user, so the method does not attribute all drift to the quantizer.

Third, every scored model is a 4-bit-weight community checkpoint, and there is no fp16-weight control run. A weight-quantization interaction cannot be excluded. The collapse is established for this checkpoint under this cache, not for the architecture as a whole.

3. What KIVI and KVQuant found, and why it does not drop in

KIVI and KVQuant independently reached the same empirical result. KIVI (arXiv:2402.02750, ICML 2024) found a small number of fixed channels with large-magnitude outliers in Key caches. Value caches did not show the same pattern. KIVI therefore quantizes Keys per channel and Values per token. Its tuning-free scales come from the live cache's minimum and maximum, with no calibration set.

KVQuant (arXiv:2401.18079, NeurIPS 2024) also starts with per-channel Key quantization. It quantizes Keys before rotary position embedding because RoPE spreads the outlier channels across dimensions. Its full method also uses sensitivity-weighted non-uniform datatypes and dense-and-sparse outlier isolation. Both require offline calibration data.

KVQuant reports under 0.1 perplexity degradation at 3-bit on Wikitext-2 and C4 across the Llama and Mistral families. KIVI runs 2-bit caches without tuning. On its serving setup, KIVI reports 2.6× less peak memory including model weights. That reduction enabled batches up to 4× larger and 2.35 to 3.47× throughput on CUDA workloads.

The peak-memory and throughput multipliers belong to that serving stack, including its batch sizes, weights, and fused CUDA kernels. They do not port to MLX. The quality findings and the bits-per-element arithmetic in section 4 do.

The Qwen2.5-7B collapse in section 2 is consistent with this picture. Per-token group-scalar quantization must stretch each group's 16 levels across any Key outlier that lands in it. The committed measurement establishes that the shipped scheme collapses on this checkpoint at 4 bits. It does not establish that Key outlier channels caused the collapse. That attribution would require a discriminating experiment, such as quantizing K and V at different widths. This repository has not run one.

One community project has tested a related split on the same checkpoint. turboquant-mlx's README reports that K quantization "destroys greedy decode" at 4 bits and below, including mlx-lm's native kv_bits=4, while V survives 3-bit. It also reports that a mixed K-at-8/V-at-4 cache decodes identically to baseline on mlx-community/Qwen2.5-7B-Instruct-4bit. This is a repository-reported result based on greedy-text equality rather than a distribution metric. A K-vs-V bit-width split also does not isolate per-channel outliers. Still, the result points in the same direction as the literature: on this checkpoint, the Keys carry the damage.

The asymmetric scheme does not drop into mlx-lm because of the decode path. MLX can already express per-channel grouping by storing K transposed so that the token axis is the last grouped axis, and mx.quantized_matmul consumes that layout directly. What breaks is decode. The quantization group now runs along the axis that grows one token at a time. A group cannot be finalized until group_size tokens have arrived. Before then, each append would rewrite a partially filled packed word. KIVI's answer is a residual buffer: recent tokens stay full-precision, Keys quantize in closed blocks once the buffer fills, and attention runs over a quantized bulk plus a full-precision tail.

That residual machinery is the main engineering work in a KIVI-style cache. It also requires layout bookkeeping that mlx-lm's attention code does not perform. HF Transformers implements this design on the PyTorch side (section 4). No per-channel-K path has been found in the surveyed public MLX implementations as of 2026-07-25, and none has been implemented or validated here. Everything in this section is literature plus layout analysis, and any port would need its own fidelity measurements before claiming the papers' numbers.

4. What other stacks ship

Hugging Face Transformers

Hugging Face Transformers ships a QuantizedCache with two backends: quanto at int2/int4, which is the default, and HQQ at int2/int4/int8. Its controls follow KIVI's shape. A quantization-axis parameter selects the layout, with axis 0 recommended for quanto and axis 1 for HQQ. A residual-length parameter controls how many recent tokens remain full precision.

The documentation is direct about the trade: "Quantizing the cache can harm latency if the context length is short and there is enough GPU memory available for generation without enabling cache quantization." The same trade needs measurement on MLX. One packaged MLX project, mlx-qsdpa, reports that its M2 Ultra implementation is faster when it dequantizes and uses fp16 SDPA below 16K, then switches to its fused kernel at longer contexts (section 5). That crossover belongs to that device, shape, format, query length, and kernel. Cache-byte savings are portable; the direction of the latency change is not.

vLLM

vLLM quantizes KV to FP8 (e4m3/e5m2), calibration-free by default with all scales set to 1.0, and with FlashAttention 3 it computes attention in the FP8 domain directly. That throughput path depends on the supported CUDA or ROCm kernels. MLX 0.31.2 exposes FP8 and MX block formats as storage (mx.quantize modes mxfp8, mxfp4, nvfp4, with matching mx.quantized_matmul support), but ships no built-in FP8-domain attention path. Low-bit KV reduces memory and can extend context when cache capacity is the binding constraint, but it does not inherit CUDA serving throughput.

Bit-width sets the cache's byte budget roughly linearly (a 64-element group's fp16 scale and bias add half a bit per element), so 4-bit is roughly a 3.6× cache reduction against fp16 and 3-bit roughly 4.6×. Those are KV-only capacity factors; usable context also depends on model weights, temporary allocations, and other runtime headroom.

5. Metal kernels

At long context, decode attention spends much of its time reading the cache. CUDA implementations fuse dequantization into attention: they read packed bytes, dequantize in registers, and avoid a full-precision K/V buffer. MLX's shipped two-matmul path already reads the packed layout through mx.quantized_matmul, so its memory saving does not require a custom kernel. By contrast, dequantizing the whole cache before fp16 SDPA creates a full-precision copy. The public record below reports a 31 GB activation spike at 128K context on a 31B model.

Why the codebook proof of concept lost

The public record is mlx #3404. Its author built a fused dequant-in-attention proof of concept through MLX's Python mx.fast.metal_kernel API for TurboQuant codebook quantization (a Hadamard rotation plus codebook lookup, not the affine scalar format used above).

The proof of concept reported cosine similarity 1.0 against its dequantized reference, but lost on wall clock to plain dequantize-plus-native-SDPA. It was 17.9× slower at 2K tokens and 3.4× slower at 32K and 64K. This was a single-layer prefill microbenchmark with 128 queries, GQA 4:1, on an M5 Max with 128 GB. The issue body first attributed the long-context gap to Python-to-Metal dispatch overhead.

One day later, the author reported results from the same kernels built as a native C++ extension. The diagnosis changed: codebook lookup was 3 to 5× slower than scalar dequantization on the GPU. Per-element indexed loads defeated SIMD coalescing even with a 16-entry codebook in L1. The author noted that llama.cpp and vLLM avoid this cost by using scalar formats.

The revised recommendation kept the rotation as an option but stored values in mx.quantize's scalar format. It also used the existing mx.quantized_matmul infrastructure, whose read path the author described as already running at native speed. The format remained the bottleneck after the dispatch layer changed, and the recommended layout is the one mlx-lm ships.

Why generic quantized SDPA is still unmerged

A maintainer declined a TurboQuant-specific built-in in favor of generic quantized SDPA and pointed to mlx PR #3026. That PR has been open since January 2026. Its current branch supports affine 4/6/8-bit at group size 32 plus MX formats. A later community benchmark on an M3 Pro measured single-token, Llama-shaped affine-4-bit decode at 1.8× the fp16 baseline at 32K, but the same report measured only 0.6× for a Gemma-shaped case at 32K. The result is shape-specific, not a general speedup. In April a maintainer cited limited review capacity; as of 2026-07-25 the PR is still open and conflicts with main, so review and integration both remain visible obstacles. Anyone planning kernel work here should read that PR first. It is the most decision-relevant object in this section.

What the community kernels report

Two community projects also publish kernels and measurements. Their claims are repository-reported and were not independently verified for this memo. mlx-qsdpa is a packaged fused decode kernel for a single query position. It reads mlx-lm's 4/8-bit affine packed layout and dequantizes inline in one dispatch. It uses a single pass up to 4,096 tokens and two-pass split-K beyond that point. The project reports 1.7× over mlx-lm's two-call path at 128K context with grouped-query attention. Its dispatcher routes contexts under 16K to plain dequantize-plus-fp16-SDPA, which it reports as the faster option.

mlx-qsdpa uses the same Python mx.fast.metal_kernel API as the #3404 proof of concept. If its numbers hold, the earlier result does not show that the Python API itself cannot win. Read with the revised #3404 diagnosis, the deciding variables appear to be the quantization format, the regime (prefill versus decode), and the baseline, rather than the dispatch layer alone.

turboquant-mlx pursues the codebook route (Walsh-Hadamard rotation plus Lloyd-Max codebooks) with fused kernels. Its README's results table on Qwen2.5-7B at 32K reports a recommended mixed K-at-8/V-at-4 configuration at 18% lower active memory and 25.84 versus 35.75 tokens/s, about 72% of fp16 decode speed. Greedy output was identical to baseline. The repository blurb's "4.6× compression at 98% FP16 speed" describes a different configuration and does not appear in the README's results table. The table is the source used here.

Neither community project publishes a distribution-level quality measurement. turboquant-mlx verifies that greedy decode reproduces the baseline's text; that is a meaningful check and a weak oracle, binary over one decoding mode and silent about how much probability mass moved underneath the argmax. This repository measures that hidden difference with KL, flip rate, and perplexity across more than fifty thousand scored positions. The same method can be used for any cache implementation that plugs into mlx-lm, including custom kernels.

6. What remains missing

1. A quality-preserving low-bit scheme on MLX. The literature's per-channel-K core (tuning-free in KIVI's form, with the residual buffer as the decode mechanism) reports near-lossless 3-bit and usable 2-bit on CUDA-side evaluations. This survey found no public per-channel-K implementation or MLX measurement as of 2026-07-25. Nearby work includes turboquant-mlx's mixed K8/V4 bit-width split, reported with a greedy-text oracle. MLX also exposes MX block formats, but mlx-lm's cache does not wire them up because QuantizedKVCache hardcodes affine mode. These formats are another candidate to evaluate. The shipped per-token scheme is measured here to degrade at 4-bit and to collapse outright on one popular checkpoint. Lower widths with the same layout are very unlikely to improve on it, though nothing here measures them.
2. MLA coverage. DeepSeek-V3-family models crash with quantized caches on mlx-lm (#1082 plus the source-level .swapaxes call in section 1, both current at drafting time). The family has no working QuantizedKVCache path in mlx-lm v0.31.3.
3. Coverage edges in upstream mlx-lm. Rotating (sliding-window) caches raise on to_quantized; batch, chunked, and composite caches skip quantization silently; the quantized attention path rejects attention sinks. (mlx-qsdpa ships repo-reported quantized rotating-cache classes, so the sliding-window gap is upstream-specific.)
4. Fidelity numbers for the community kernels. Both fused-kernel projects report speed and text-equality; neither reports KL, flip-rate, or perplexity-delta measurements. Until someone runs them, their speed columns have no measured quality column next to them.
5. A merged fused path. The generic quantized SDPA exists as an open, unmerged PR (#3026) with shape-dependent long-context results, an earlier review-capacity concern, and a branch that currently conflicts with main; one community decode kernel reports 1.7× at 128K through the Python kernel API. Whether and when a fused path lands in MLX core, and how it performs across regimes, remains publicly unsettled.

This memo implements nothing. It reports no per-channel-K result on MLX and found none in the surveyed public projects as of 2026-07-25. CUDA throughput and system peak-memory multipliers do not port to Metal. Key outliers remain a hypothesis for the Qwen2.5-7B collapse, consistent with the literature and one repository-reported K-vs-V split but not demonstrated here.

7. Claims and status

8. Practical lessons

Checking mlx-lm first changes the work. A plan written without reading its source could rebuild QuantizedKVCache and mistake it for a new feature.

The incumbent also needs measurement before replacement. "4-bit KV quantization degrades quality" is too vague to guide a design. The committed reports are more useful: 8-bit costs little in the mean but receives a marginal verdict on two of three checkpoints. At 4-bit, two checkpoints degrade and one fails. A demo that checks only greedy output could miss that difference.

KIVI's quality result can motivate work on MLX. Its peak-memory and throughput numbers cannot be copied across platforms because they include its serving stack. Bits per element is the portable part; system throughput and peak memory need new measurements.

The kernel record also warns against blaming the launch mechanism too early. The initial report blamed Python dispatch. The same author's C++ port found a larger cost in the codebook's per-element indexed loads and recommended the scalar format already supported by MLX. Baseline, format, and dispatch need separate measurements.

In short, low-bit cache work needs both speed and distribution-level quality evidence. The community kernels currently publish compression and throughput without the latter. This repository already measures KL divergence, flip rate, and perplexity delta for implementations that can plug into mlx-lm.

References and source notes

• mlx-lm at the v0.31.3 tag (matches the installed version used for verification): models/cache.py (QuantizedKVCache, to_quantized, rotating-cache NYI), models/base.py (two-matmul quantized attention, sinks rejection, dispatch), generate.py (--kv-bits, --kv-group-size, --quantized-kv-start), models/deepseek_v3.py (the MLA .swapaxes call site).
• MLX: mx.quantize documentation; issue #3404 (fused-PoC timings, the author's revised codebook diagnosis, the maintainer's direction); PR #3026, "Quantized SDPA" (open).
• mlx-lm issue tracker: #1082 (MLA / DeepSeek-V3 crash with quantized caches, open).
• mlx-quant-fidelity committed evidence: sample fidelity reports, measurement principles, threshold policy, README.
• Papers: KIVI, arXiv:2402.02750 (ICML 2024); KVQuant, arXiv:2401.18079 (NeurIPS 2024).
• Other stacks: HF Transformers cache strategies (QuantizedCache, axis and residual-length knobs, short-context latency warning); vLLM quantized KV cache (FP8, calibration-free default, FA3 FP8-domain attention).
• Community Metal kernels (claims repo-reported): turboquant-mlx, mlx-qsdpa.

Prepared 2026-07-25. Last updated 2026-07-25. Denis Ineshin.
