When the Bottleneck Moved: From Fused Cross-Entropy to FlashAttention on MLX

Denis Ineshin · 2026-07-20

Two corrected system models and a tiled attention path for Apple GPUs

Removing a large allocation does not necessarily move a system's memory ceiling. It moves the ceiling only when that allocation is alive at the peak.

That distinction cost mlx-train-perf its first product hypothesis. A fused linear cross-entropy forward removed the (tokens, vocabulary) logits matrix, and at moderate sequence lengths an end-to-end training run used less memory. We expected the saving to extend the longest context that fit on a 32 GB Mac. It did not. At 8192 tokens, the fused-loss and stock-loss training paths reached the same 21.39 GiB marginal peak above resident state. Together with that tie, an isolated attention operation whose forward-plus-backward window peaked at 12.75 GiB pointed to the credible dominant shared term: a quadratic-memory attention backward. The experiments did not directly trace the lifetime of the loss buffers, so they do not establish the ordering or overlap of the loss and attention peaks.

The next implementation replaced that quadratic-memory backward with tiled recomputation on Metal. At 8192 tokens, the release documents report a 12.75 GiB total peak for flash attention plus fused loss against 25.68 GiB for stock attention plus stock loss. This full-product comparison changes two components at once, and the public evidence does not contain a complete memory 2×2 (both attention paths crossed with both loss paths) that could assign an order-independent share to either component.

One more model then failed. The first release of the flash path capped the total projected duration of a chained Metal launch. MLX source inspection and a dedicated packing probe showed that successive large production ranges cannot share one command buffer under the pinned scheduler thresholds, so a chain-total cap did not model how MLX submitted that work. Smaller framework work may still precede the range in the buffer it closes. The evidence is consistent with command-buffer occupancy being relevant to macOS interactivity kills, but it does not directly observe the operating system's decision rule.

The project README and changelog report a later context sweep reaching 23,040 tokens on the flash-plus-fused path versus 7,936 on the stock path on the same M1 Max. This article treats those as source-reported measurements; it does not independently rerun the benchmark. The public release record does not include the raw failed probes above 23,040, so it cannot establish a pure post-correction memory frontier for an outside reader.

This paper is a case study in bottleneck migration and measurement correction. It does not claim a new attention algorithm: the online-softmax and recompute schedule comes from FlashAttention. The contribution is not the first Metal or MLX FlashAttention implementation. It is a causal grouped-query-attention (GQA) training integration for Qwen/Llama-class mlx-lm fine-tuning on pre-NAX Apple hardware, the generations before the M5's Neural Accelerators, together with the evidence trail showing how two plausible system models failed.

1. The first hypothesis: remove logits, train longer

For sequence length N, hidden dimension D, and vocabulary size V, a conventional output layer forms logits with shape (N, V):

logits = hidden @ W.T
loss_i = logsumexp(logits_i) - logits_i,target_i

The fused loss avoids that matrix. It streams over vocabulary tiles, updates an online log-sum-exp, captures the target logit, and returns only per-token vectors. This removes a real allocation. The initial product hypothesis went one step further: if logits disappear, a longer sequence should fit before the machine runs out of memory.

We tested that prediction on an Apple M1 Max with 32 GB unified memory using MLX 0.31.2, mlx-lm 0.31.3, and mlx-community/Qwen3-8B-4bit. Both arms used batch 1, LoRA rank 8 across all layers, bfloat16 compute, AdamW, gradient checkpointing, and the compiled mlx-lm training loop. Every context probe ran in a separate subprocess and executed two real fine-tuning steps. The search doubled the context and then bisected to a 256-token granularity.

The result contradicted the hypothesis. The values below, from the dated project record, are source-reported marginal peaks above roughly 4.29 GiB of resident model state; later tables use a different metric, the total peak:

The fused path helped at 2,048 and 4,096 tokens. By 8,192, the reported marginal peaks were equal at the available precision. The largest successful contexts were 8,448 for the fused path and 8,704 for stock, one search step apart and reversed from the prediction. The honest interpretation was a tie, not a small loss for fusion.

These values come from the dated research record that preceded the public benchmark bundle. That record includes the environment, search procedure, and result table summarized here, but its raw per-probe artifacts and original sweep driver were not published. The table is therefore an attributed historical result, not an independently reproducible result from the current repository.

This experiment also corrected the meaning of an earlier measurement: the loss layer in isolation, where the fused kernel's marginal memory had looked far smaller than stock's. That isolated ratio used unequal warmed baselines and is not a sound end-to-end multiplier. The 0.72 GiB saving at a 2,048-token training point is a more relevant observation: real memory was freed at that shape, but the long-context high-water mark was dominated by a shared term. Proving the exact allocation lifetime would require phase-scoped instrumentation.

2. Finding the allocation that replaced it

The shape of the training curve pointed away from vocabulary logits. When N doubled from 2,048 to 4,096 and then 8,192, the peak grew much faster than linearly. Both loss arms converged on the same curve. That supports a shared dominant term but does not identify allocation lifetimes.

A direct scaled-dot-product-attention experiment measured the candidate term. The dated research record reports an inline experiment with one causal mx.fast.scaled_dot_product_attention operation, 32 heads, head dimension 128, and bfloat16 inputs. It evaluated materialized inputs, cleared the cache, reset MLX's peak-memory counter, and measured forward-only and gradient evaluations separately. The raw result artifact and a standalone historical driver are not part of the public evidence bundle. The MLX fast path had a memory-light forward, but its training backward fell back to an unfused implementation:

Forward memory doubled with N; forward-plus-backward memory grew by about 3.7 to 3.8× per doubling. At 8,192 tokens, the isolated attention operation's full forward-plus-backward window reached about 12.75 GiB. Three observations support attention backward as the credible shared bottleneck: the operation's scale and rapid growth, the converging loss-arm curves, and the later attention intervention. They do not establish when the loss buffers were released or whether the two peaks overlapped.

The behavior also matched pinned MLX source. In MLX 0.31.2 and MLX 0.32.0, the Metal fast-SDPA training path fell back, and the 0.32.0 VJP GPU implementation was marked NYI (not yet implemented). The missing component was not another loss optimization. It was a memory-efficient attention backward.

3. What the FlashAttention schedule changes

For one attention head, standard scaled dot-product attention is

S = scale · Q Kᵀ + mask
P = softmax(S)
O = P V

A straightforward training implementation stores or reconstructs an (N, N) score or probability matrix. FlashAttention changes the schedule rather than the result. It processes query and key/value blocks, keeps softmax state on chip, and writes only the output and one log-sum-exp (LSE) value per query row.

For a score tile S_ij, the forward tracks a row maximum m, a scaled denominator l, and an unnormalized output accumulator acc:

m_new   = max(m_old, rowmax(S_ij))
alpha   = exp(m_old - m_new)
p       = exp(S_ij - m_new)
l_new   = alpha · l_old + rowsum(p)
acc_new = alpha · acc_old + p V_j

After all visible key blocks:

O_i = acc / l
L_i = m + log(l)

The backward saves O and L, not P. It recomputes each probability tile as

P_ij = exp(scale · Q_i K_jᵀ + mask_ij - L_i)

and accumulates dQ, dK, and dV tile by tile. The saved attention state is proportional to N·D, rather than N². This is algorithmic saved-state complexity; it does not imply that every measured device peak must double exactly when N doubles. Temporary outputs, split reductions, allocator state, and the rest of the training step remain visible to the measurement.

The first MLX/Metal implementation supported causal training attention for Llama and Qwen3-style layouts, including grouped-query attention. Its forward wrote O and L. The backward used a small preprocess for D_i = dot(dO_i, O_i), a query-owned dQ path, and split/reduced dK and dV work. Unsupported masks, dropout, head dimensions, model families, and inference caches failed with typed errors instead of silently changing implementation.

The released correctness evidence separates into four checks, each with its own comparator and scope:

The release-tagged forward and backward grids cover causal MHA and GQA, sequence lengths 61, 64, and 257, head dimensions 64 and 128, batches 1 and 2, and fp32/bf16 inputs; the 32-query/8-KV-head pattern is included at length 64. These are acceptance tolerances, not production-shape observed maxima. The 2.4e-3 figure measures integrated loss-curve agreement, not elementwise attention error.

4. Separating the attention win from the loss win

The 0.2 release benchmark used MLX 0.32.0 on the same 32 GB M1 Max, with Qwen3-8B-4bit, batch 1, LoRA rank 8, bfloat16 compute, and gradient checkpointing. The public README and changelog report the following 8,192-token outcomes; the raw train-step JSON is not committed, so values are rounded to the public release precision:

The full-product comparison, flash plus fused loss against stock attention plus stock loss, was close to a twofold reduction in total peak. It changed two components at once. The fixed-stock-loss throughput comparison establishes that both attention paths ran, but its flash memory value is not in the public release evidence. Because one cell aborted and the public bundle lacks a complete memory 2×2, the experiment cannot estimate interaction or assign an order-independent share of the full reduction to either component.

The stock-attention plus fused-loss cell aborted while the stock-loss cell completed. The release documents do not expose enough session state to explain that ordering as a monotonic allocation result. The missing cell must remain missing; it cannot be reconstructed from the other three.

The committed single-op reproduction compares the flash kernel with the project's materialized pure-MLX mathematical reference. It does not measure mx.fast.scaled_dot_product_attention and must not be read as an installed-MLX stock-path comparison. Its values are marginal device peaks after implementation-specific warm-up and an active-memory baseline reset:

The flash measurements are consistent with the intended linear saved-state design, but three points do not constitute an asymptotic proof. The 4,096→8,192 measured peak grows by 3.06× because the metric includes more than the persistent O and L arrays. The safe claim is that the implementation avoids the full score matrix and measured far below the stock path at the tested long-context shapes.

5. The second wrong model: budgeting the whole chain

The project treated long-running Metal work as an interactivity and kill risk. Its operating hypothesis was that sufficiently long non-preemptible GPU work could starve display compositing, but the available evidence did not directly establish preemption behavior, starvation causality, or the macOS kill unit. The 0.2 implementation therefore estimated kernel duration and split work before a dispatch crossed its conservative budget.

The original guard also capped an entire chained backward at two projected seconds. Its model assumed that MLX packed consecutive custom-kernel dispatches into one command buffer and treated the whole packed chain as the safety unit. This cap refused flash-attention contexts near 10,000 tokens even though their memory peaks remained well below the machine ceiling. The result looked like a new bottleneck: fusion removed the quadratic memory limit, only to expose a RAM-independent launch limit.

That explanation was wrong.

MLX 0.32.0's Metal scheduler commits after encoding when more than 50 operations or more than roughly 50 million unique input/output elements have accumulated on the M1 Max architecture class. Its source counts backing-buffer identities, not semantic tensor liveness. At the 8,192-token training shape, a single dK/dV range touches about 118 million elements and a dQ range about 85 to 89 million. Successive ranges of that size therefore cannot share one command buffer: each triggers a commit after it is encoded, although smaller preceding work may share the buffer it closes. The chain total is not the duration of one command buffer.

A source-reported behavioral probe, using the public probe_command_buffer_packing.py method, was consistent with the scheduler thresholds being active in the shipped wheel. For example, forcing a boundary after every operation made a chain of 2,000 tiny serial matrix multiplies 2.8× slower, an aggregate cost associated with more frequent commits rather than an isolated fence measurement. A separate N=12,288 chained dK/dV probe, nominally beyond the retired total-chain budget, completed in 0.781 s wall with finite outputs and a 1.56 GiB peak. The raw probe JSON is not in the public bundle.

The corrected guard models work per command buffer. It keeps the worst-day safety margin for each buffer and accounts for small dispatches that can still pack together. No safety margin was raised. This is a source-grounded conservative model, not a direct measurement of the macOS watchdog's internal decision boundary.

6. The source-reported context sweep

After the guard correction, the project ran the sweep that its README and changelog report: Qwen3-8B-4bit QLoRA, batch 1, LoRA rank 8, bfloat16 compute, gradient checkpointing, and two training steps per isolated probe. The two documents agree on the following source-reported results:

The ratio of the reported largest completed points is 2.90× on this machine and this run. It is not a universal context multiplier. The comparison changes both attention and loss, uses one model and batch size, and depends on the available-memory ceiling at probe start. Larger-memory hardware was not measured, and this article did not rerun the sweep.

The release documents call both completed frontiers memory-bounded, but the raw failed probes are not in the public evidence bundle. The reported ceilings and ratio can therefore be cited as release results; the precise failure sequence above 23,040 and a pure post-correction memory frontier cannot be independently audited here.

The supported editorial claim is narrower: the project documents report a two-step execution at 23,040 tokens with roughly the total peak that stock used at 7,936. This is a documented single-machine result, not an independently reproduced trainability or scaling result.

7. Lessons from two displaced bottlenecks

The sequence of experiments supports five conclusions.

First, allocation size is not enough. Lifetime determines whether an optimization changes peak memory. The logits matrix was large, while the converging train-step curves and isolated attention scaling identified attention backward as the credible shared bottleneck; their relative phase ordering was not measured.

Second, component controls matter. The twofold full-product reduction at 8,192 tokens combined fused loss and flash attention. The isolated attention scaling shows why attention credibly contributes a substantial share, but the incomplete public 2×2 does not decompose the full reduction.

Third, algorithmic complexity and measured scaling are different statements. FlashAttention keeps linear saved state, while measured device peaks include temporary reductions, allocator behavior, and the surrounding training graph.

Fourth, safety models deserve the same empirical scrutiny as performance models. The per-chain guard was conservative but did not match observed MLX submission boundaries. It blocked valid observed work; the stronger claim about the exact macOS watchdog unit remains an inference.

Finally, failed and refused cells are part of the result. A watchdog abort, a launch refusal, and a successful measurement answer different questions. Collapsing all three into "does not fit" hides the mechanism that should guide the next design.

8. Limitations and reproducibility

The evidence comes from one M1 Max with 32 GB unified memory, two pinned MLX releases, one flagship Qwen3 recipe, and short two-step context probes. Absolute ceilings depend on machine availability, thermal and display state, software versions, and the active safety ceiling. The context sweep measures two short steps, not training quality over a meaningful optimization run. This article cross-checks the reported figures against existing project documents and does not rerun the research code.

The algorithms and benchmark drivers are public in this repository:

• scripts/bench_attention_op.py measures isolated attention memory and wall time.
• scripts/bench_train_step.py measures the attention/loss combinations.
• scripts/northstar_context_sweep.py performs the context search.
• scripts/probe_command_buffer_packing.py tests the scheduler model.

The committed community artifact contains the MLX 0.32.0 single-op measurements through 8,192 tokens. The release README and changelog record the train-step and context results. Raw JSON for the train-step, context-sweep, and command-buffer campaigns is not part of the public evidence bundle, so this is a source-based technical article, not an independently reproducible benchmark report.

Related work

FlashAttention introduced the IO-aware exact tiled algorithm for the quadratic attention-memory bottleneck this paper targets; FlashAttention-2 improved work partitioning and reduced non-matrix-multiply overhead. Cut Cross-Entropy and Liger-Kernel address the separate (tokens, vocabulary) logits bottleneck. Their relevance here is the systems interaction: removing loss-layer materialization does not increase end-to-end context when an O(N²)-memory attention backward becomes the next peak.

Closer Apple-platform implementations predate this work. Metal FlashAttention 2.0 published Swift/C++ Metal kernels and an experimental backward for diffusion training in January 2025. mlx-mfa 2.37.1 was already an MLX attention runtime with training support by May 2026; its native NAX backward was opt-in on M5+ for a restricted non-causal fp16/bf16 envelope, with other paths using SDPA VJP. The implementation studied here instead targets native causal MHA/GQA forward and backward on an M1 Max and integrates it into Qwen/Llama mlx-lm QLoRA. It does not claim first implementation, parity with optimized CUDA throughput, or support for arbitrary attention modes.

Prepared 2026-07-14. Last updated 2026-07-20. Denis Ineshin.
